O - 30 MPH IN 2.0S
ONYX RCR
100%
125CC 4T
80%
2-Stroke Power-Band Fast
Experience the power-band torque of kitted two stroke motors throughout the entire RPM range. Get up to speed in 2 seconds or take it off road and unleash the full potential up to 55+ mph.
SPECS
Max Power Output
15.2kW (@84.2V)
Max Boost Power Output
10.1kW (@84.2V)
Nominal Power Output
7.2kW (@72V)
Max Voltage
84.2V
Nominal Voltage
72V
Battery
3,240Wh | 45Ah | 100A Constant | 130A Boost (8 min) | 200A Peak (3 sec)
Battery Connectors
Discharge Anti-Spark QS8 | Charge
3-Pin XLR
Battery BMS
Smart Bluetooth BMS
Auxiliary 12V System
72V to 12V Convertor
Auxiliary USB System
12V to 5V Convertor
Charger Speed
84V - 10A | 10-80% (2.5 hours) | 0-100% (4.5 hours)
Acceleration
0-30MPH in 4.0 Seconds*
Speed Modes
Eco (20mph) | Normal (40mph) | Sport (55+ mph)
Normal and Sport are for off-road use only.
Range
With 41Ah battery
Eco (120 miles) | Normal (70 miles) | Sport (45 miles)
Throttle Control
Ride-By-Wire
Motor
750W Eco | 3,000W Normal | 5,000W Sport | Hi-Torque Hub Drive
Regenerative Braking
40A Max Regen
Drive Modes
Eco / Normal / Sport
Pedal Drive
Human Assisted Pedal Drive
Motor Controller
300A Sinusoidal MOSFET
Frame
Steel Tube Chassis
Body Panels
Aluminum Side Panels + 5-Ply Maple Skate Deck Wood Cover
Battery Case
Steel Case
Front Suspension
Hydraulic Disk Brake Fork | Steel Fork Brace |12mm Through Axle
Rear Suspension
Adjustable Shocks | Shorty (300mm) | Standard (350mm)
Fork Dust Cover
Rubber Fork Gaiters
Headset
Malossi MVR 32005X Tapered
Headset Bearing
Front Brake System
Hydraulic Disk Brake Caliper | 220mm Rotor
Rear Brake System
Dual-Piston Line Pull Hydraulic Caliper | 203mm Rotor
Wheels
17″ 36 Spoke
Tire Specs
Street | 3.00" x 17"
Pedals
BMX Platform Pedals
Pedal Chain
1/8" Black Alloy Steel Chain
Seat Positioning
82mm of Length Adjustment | 4 x M6 Holes (60mm W x 155mm L)
Seating
2" of Comfy Foam w/ 16" of Seating Space (19" L x 7" W x 4"H)
Rear Sprocket
16T BMX Freewheel
Kickstand
Steel Side Stand
Pedal Crank Shaft
28T Chrome Steel Crank
Pedal Cranks
125mm ONYX Puch Moped Style
Rear Rack
Optional (Sold Separately)
Headlight
LED Projector + Halo DRL
Tail Light
LED
Blinkers
LED
Electronic Controls
Power | Speed Modes | Lights | Blinkers | Horn
Manual Controls
Half-Twist Throttle | L + R Hand Brake Levers
Controller Settings
Customizable w/ Bluetooth Module (Sold Separately)
Battery Health Monitoring
Downloadable Bluetooth
App - Hyperlink
Battery Cover
Lockable w/ Key
Accessory Charging
USB A
Alarm
Extremely High dB Speaker | Remote Key
Display
LCD Backlit
Display Functions
MPH | Real-Time Volts | Battery Meter | Trip Meter | Odometer
Display Indicators
Speed Modes | Turn Signals | Lights
